Description

The Fire-Ball 425 is the pump of choice for your most demanding high volume applications – an ideal choice for applications such as truck fleet service facilities and in-plant applications where multiple dispenses happen at the same time.

• Durable – Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs – Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Extended Seal Life – In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
• Reduce Downtime – Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
• Superior Sealing – Non-metallic poppet valves offer positive sealing performance, even with contaminated “dirty” air environments for long life without repair.
• Reduced Icing – Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant – Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

Air Inlet Size (in)	0.5
Air Inlet Thread Gender	Female
Air Inlet Thread Type	NPT
Air Motor Effective Diameter (in)	4.25
Application	Industrial
Compatible Material	Oil
Construction	Steel, Polyurethane, Aluminum, Nitrile
Cycles Per Gallon	6
Fluid Inlet Size (in)	1-1/2
Fluid Inlet Thread Gender	Female
Fluid Inlet Thread Type	NPT
Fluid Outlet Size (in)	3/4
Fluid Outlet Thread Gender	Female
Fluid Outlet Thread Type	NPT
For Use With	Petroleum- and synthetic-based oils (motor, gear and ATF)
Maximum Air Inlet Pressure (psi)	180
Maximum Continuous Cycle Rate (CPM)	66
Maximum Intermittent Cycle Rate (CPM)	66
Maximum Working Pressure (MPa)	3.7
Maximum Working Pressure (psi)	540
Model	Fire-Ball
Power Type	Pneumatic
Pump Ratio	3:1
Series	425
Sound Pressure Level (dB(A))	82
Type	Pneumatic Piston Pump
Weight (lb)	46
